| Place of Origin: | China |
| Brand Name: | RealRun |
| Certification: | ISO9001, SGS, Rohs, Reach |
| Model Number: | PH2.0*2.0-2*nPBW |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | CAP+Reel Tape Packing/Tube Packing |
| Delivery Time: | 3~7workdays |
| Payment Terms: | L/C, T/T, Western Union,PayPal |
| Supply Ability: | 100000pcs/day |
| Color: | Black | Pitch: | 2.0mm |
|---|---|---|---|
| Plastic Height: | 2.0mm | Insulator Material: | PA6T+30%Glass Fiber, UL94V-0 |
| Contact: | Brass | Contact Plating: | Gold/Tin Over Nickel |
| Current Rating: | 2A | Contact Resistance(max): | 30mΩ Max |
| Insulation Resistance(min): | 1000MΩ Min | Processing Temperature: | 260℃ For 10 Seconds |
| Operating Temperature: | -40℃ To +105℃ | ||
| High Light: | SMT 2A Pin Header Connector,2.0mm Height Pin Header Connector,50pin Dual Row SMT Connector |
||
Product Description:
Connector manufacturers, professional in producing connector for more than 15 years
We are specialized in electronic connectors, electronic wire harnesses and hardware development, if you couldn't find the exact items you need, please send us your drawings or pictures, we will provide the best solution for you.
High quality 50 pin dual row right angle SMT type pin header connector
Product features: The male pin connector has a wide range of application, environmental protection, fire prevention, strong oxidation resistance and electrical conductivity. It is blocked or isolated between circuits to achieve the bridge function and undertake the task of current or signal transmission.
Product material: Its materials are pure copper wire, brass wire, phosphor copper wire, copper-clad steel wire, nickel plating and nickel plating on the surface.
Scope of application: Pin header are widely used in monitors, digital cameras, MP3,MP4,PDA, computers, computer motherboards, mobile storage disks, card readers, safety products, electricity meters, wireless phones, mobile phones, interphones, program-controlled switches, VCD,DVD,LCM / LED display module, electronic toys, household appliances, etc. Provide the most reliable connection for board-to-board and line-to-board
| Name | Pin Header Connector/PCB Connector |
| Pitch | 2.0mm |
| Plastic Height | 2.0mm |
| Type | Right Angle SMT Type |
| Insulator Color | Black/Grey |
| Insulator Flammability | PA6T+30%Glass Fiber, UL 94V-0 |
| Current Rating | 2A |
| Contact Resistance(max) | 30m ohm |
| Insulation Resistance(min) | 1000M ohm |
| Contact materials | Brass |
| Contact Plating | Gold/Tin over nickel |
| Operation Temperature | -40℃ to +105℃ |
| Processing Temperature | 260℃ for 10 seconds |
| Packing | Tray Packing |
| OEM/ODM | Accepted |
| Mounting Type | Through Hole |
| Termination | Customization |
| Contact Shape | Square Pin |
| Pin Available | 2 Pins to 80 Pins |
Please feel free to contact us and we will send you the drawings you need.
When can we get the reply?
We will repliy within 12 hours.
What should I do if I encounter quality problems?
1. This kind of situation will not happen basically. Before shipment, we will carry out multi-level check to confirm that there is no product quality problem before packaging and delivery.
2. In case of such a thing happening, we will negotiate with you about the handling plan and assure you that it will not happen again in the future.
3. If you encounter quality problems in the receiving process, RealRun will take full responsibility for the cost of return and replacement caused by product quality problems.
About the mode of transportation?
1. Land Transportation.
2. ocean transportation.
3. air transportation.
About packaging?
Reel/tray/tube/inner box+outer carton packing or the packaging method you need.
