| Place of Origin: | China |
| Brand Name: | RealRun |
| Certification: | ISO9001, SGS, Rohs, Reach |
| Model Number: | PH2.54*H-3*nP 12Pin |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | CAP+Reel Tape Packing/Tube Packing |
| Delivery Time: | 3~7workdays |
| Payment Terms: | L/C, T/T, Western Union,PayPal |
| Supply Ability: | 100000pcs/day |
| Place Of Origin: | Guangdong, China | Brand Name: | RealRun |
|---|---|---|---|
| Color: | Black | Pitch: | 2.54mm |
| Plastic Height: | 2.5mm | Insulator Material: | PA6T+30%Glass Fiber, UL94V-0 |
| Contact Material: | Brass | Contact Plating: | Gold Or Tin Over Nickel |
| Current Rating: | 3A | Contact Resistance(max): | 20mΩ Max At DC 1A |
| Insulation Resistance(min): | 1000MΩ Min At DC500V | Operating Temperature: | -40℃ To +105℃ |
| High Light: | PA6T Solder Header Connector,2.54mm Pitch Solder Header Connector,DIP Three Row Header Connector |
||
Product Description:
Connector manufacturers, professional in producing connector for more than 15 years
We are specialized in electronic connectors, electronic wire harnesses and hardware development, if you couldn't find the exact items you need, please send us your drawings or pictures, we will provide the best solution for you.
PA6T Black 2.54mm Full Gold Connector 3*4 12 Pin Header 180° DIP Three Row
Product features: Widely used, environmental protection, high temperature resistance, fire resistance, oxidation resistance.
Product material: Pin header material: brass or phosphor bronze; Insulator material: plastic UL94V-0. Surface treatment: gold plating, tin plating, nickel plating.Strong conductivity, stable signal transmission performance.
Scope of application: It has a wide range of applications and is usually suitable for data processing, computer, program control equipment, electronic measuring equipment, automatic control, automation, communication.
The face of strong demand customization, our strong R&D center, mold manufacturer and processing center, which can quickly grasp customer needs, providing OEM/ODM products with the most reliable product and precise connectors for different customers.:
| Name | Pin Header Connector/PCB Connector |
| Pitch | 2.54mm |
| Plastic Height | 2.5mm |
| Type | DIP Type |
| Insulator Color | Black/Grey |
| Insulator Material | PBT+30%G.F, UL 94V-0 |
| Current Rating | 3.0Amp |
| Contact Resistance(max) | 20m ohm Max at DC 3Amp |
| Insulation Resistance(min) |
1000M ohm Min at DC500V |
| Contact materials | Brass |
| Contact Plating | Tin or gold over nickel |
| Operation Temperature | -40~105℃ |
| Packing | Bag Packing/Tape&reel+CAP Packing |
| OEM/ODM | Accepted |
| Mounting Type | Through Hole |
| Termination | Customization |
| Contact Shape | Square Pin |
| Pin Available | 2Pin~80Pin(Customized) |
Please feel free to contact us and we will send you the drawings you need.
What's the Pin Header
1. Pin header is called universal connector. Based on different designs for PCB,they choose different pitch connectors to meet.
2. 0.8mm/1.0mm/1.27mm/2.00mm/2.54mm 3.96 pitch pin header are featured products in our company. If you need special pin header that standard pitch couldn't satisfy, e-mail or call our sales team.
3. Generally, pin headers with suited female headers are used to finish created modules in electronic industry.
4. Regarding pin header electrical and mechanical properties, same pitch has the same function, which we have shown clearly in our data sheet.
5. Another common variation on pin header is called "machine pin" version. The normal version is formed out of stamped and folded sheet metal, machine pin connectors are formed by tooling the metal into the desired shape, which is a more robust, with a better joint and longer life, making it more expensive though. Still more and more automotive and medical industry customers choose machine pin to improve connection stability.
FAQ
Q: Can I get some samples?
A: Yes,some samples are free.
Q: If happend with the defective products when receiving the goods, how to deal with?
1. Next to impossible of the goods will be not good as before the shipping, we have many chekings to confirm the products is no problem. Then if happened, RealRun will bear all the responsibility.
2. First: why this will be happen, how happen, and how to control in the future, a table will be come out for your checking.
3. Second: discuss the solutions.
4. Finally: RealRun will bear all the fees if returning and changing the goods or the loss caused.
Q: Are you manufacture of trading company?
A: We are a manufacture in Shenzhen, China.
Q: Is it OK to print my logo on the packing?
A: Of course, customized packing accepted!! But it may bring some cost, it depends on the qty and the packing.
