Specialized in Connector OEM/ODM 13 Years
Sales & Support:
 |
| Place of Origin: | China |
| Brand Name: | RealRun |
| Certification: | ISO9001, SGS, Rohs, Reach |
| Model Number: | FH2.54*8.1-1*nW 7W |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | CAP+Reel Tape Packing |
| Delivery Time: | 3~7workdays |
| Payment Terms: | L/C, T/T, Western Union,PayPal |
| Supply Ability: | 100000pcs/day |
| Pitch: | 2.54Mm | Insulator: | PA6T/PBT UL94V-0 |
|---|---|---|---|
| Current Rating: | 2A | Contact Resistance(max): | 20m Ohm Max At DC2A |
| Insulation Resistance(min): | 1000M Ohm Min At DC500V | Contact: | Brass |
| Contact Plating: | Gold/Tin Over Nickel | Withstanding Voltage: | 500V AC/minute |
| Operation Temperature: | -40℃ To +105℃ | ||
| High Light: | PA6T Female Header Connector,LCP Brass Female Header Connector,DC2A Right Angle Header Connector |
||
Product Description:
Connector manufacturers, professional in producing connector for more than 15 years
We are specialized in electronic connectors, electronic wire harnesses and hardware development, if you couldn't find the exact items you need, please send us your drawings or pictures, we will provide the best solution for you.
2.54Mm Pitch Female Header Connector Single Row Bend Pins Right Angle 1*7P PA6T
| Product name: 2.54mm female header connector | ||
| 1. product features: the use of a wide range of environmental protection, high temperature, fire resistance, oxidation resistance. | ||
| 2. product function :Its function is to act as a bridge between the blocked or isolated circuits, and to take on the task of current or signal transmission. | ||
| 3. scope of application: widely used in electronics, electrical appliances, instruments in the general connection of the main components of the current or signal transmission. Usually with the needle supporting the use of a board to board connection. The utility model is matched with an electronic wiring harness terminal to form a board to wire connection. |
Please feel free to contact us and we will send you the drawings of you need:
Our Services:
1. We value our customers’ trust in sourcing for the most suitable components for their requirements.
2. We only offer what is best for our customers, knowing each customer is unique.
3. Our fast, innovative service will ensure that our customers’ needs are answered
4. We value every customer, no matter small or medium volume orders.
5. Our business is not just about components supply, it’s about delivering promises.
6. Our aim is make sourcing connector easy for you
7. We'll reply your inquiry within 12hours,Online Inquiry is Welcome.
8. We provide OEM,ODM services
9. 20pcs free samples, For repeat order customer, We'll provide more than 20pcs samples for prototype project if necessary.
10. Your one-stop source for components solutions.
FAQ
Q: Can I get some samples?
A: Yes,some samples are free.
Q: Who do I contact if I have a technical questions?
A: We have an experienced team of technical sales representatives in house. They are ready to answer any questions you may have and assist you in your project.
Q: If happend with the defective products when receiving the goods, how to deal with?
1. Next to impossible of the goods will be not good as before the shipping, we have many chekings to confirm the products is no problem. Then if happened, RealRun will bear all the responsibility.
2. First: why this will be happen, how happen, and how to control in the future, a table will be come out for your checking.
3. Second: discuss the solutions.
4. Finally: RealRun will bear all the fees if returning and changing the goods or the loss caused.
Q: How do you guarantee my goods right?
A: Order will be arranged exactly as requested, we will doubly check the packing and qty before delivering out also we will take you photos if required or necessary.
Q: Which payment can be accepted:
1. The payment terms can be flexiable depend on the quantity and products.
2. Usually, new customer we prefer the 100% T/T before shipping or 30%T/T advance before shipping.
